| Priter Brand | Zebra ZE511-4 |
| Application Type | Tamp-On |
| Media Output | Left / Right |
| Labeling Position | Side |
| Print Method | Thermal Transfer / Direct Thermal |
| Resolution | 203/ 300 DPI |
| Printing Speed | 305MM/S(203DPI) |
| 254MM/S(200DPI) | |
| Labeling Width | 20-104MM |
| Labeling Length | 20-990MM |
| Liner Width | 16-114MM |
| carbon band Width | 25.4-107MM |
| carbon band Thickness | 0.06-0.3MM |
| carbon band Parameters | Core Diameter: 25.4 mm |
| Outer Diameter: 101.61 mm | |
| Length: 600 m | |
| Wind: Wax Side Out | |
| Sensing Mode | Gap Sensor (Transmissive) / Reflective Sensor |
| Label Type | Continuous / Die-Cut (Pitch)/Pre-Die-Cut Labels/Black-Mark Labels |
| Coated Paper/Synthetic Paper/Glassine Liner / Glassine Backing | |
| Label Roll Dimensions | Inner Diameter φ76.2MM |
| Outter Diameter: φ300MM | |
| External Interfaces | RS232 Serial Port / Parallel Port / USB 2.0 / Ethernet Port |
| Memory | 16MB SDRAM、64MB Flash Memory |
| Operating Panel | Touch Screen |
| Pneumatic System | FESTO |
| Overall Dimensions | L820*W670*H1600MM (Customizable） |
| Labeling Speed | ≤15P/min |
| Lableling Accuarcy | ±2MM |
| Power Supply Specification | 220V/50HZ 1.5KW |
| Machine Weight | 100KG |
Precision at Speed: The Ultimate Swing-Arm Print & Apply Solution
Streamline your packaging and logistics line with fully automated, on-demand labeling. Integrate printing and application in one compact, high-speed system.
*Unmatched Flexibility: The articulated swing-arm reaches top, side, or front labels with ease, accommodating a wide range of product sizes and shapes.
*Maximum Uptime: Robust construction and reliable components ensure continuous operation in demanding industrial environments, minimizing downtime.
*Effortless Integration: Seamlessly connects with your existing ERP, WMS, or PLC systems via Ethernet, USB, or serial interfaces for real-time data printing.
*Pinpoint Accuracy: Advanced sensing and servo-driven motion guarantee precise label placement every time, eliminating misapplies and reducing waste.
*E-commerce & Warehousing: Apply shipping labels, SSCC labels, and barcode labels to cartons of all sizes.
*Manufacturing & Production: Print and apply VIN labels, component labels, and compliance labels directly on the production line.
*Food & Beverage: Handle date-coding, ingredient, and traceability labeling with food-safe materials.Pharmaceutical & Medical: Ensure 100% accuracy for serialized product identifiers and regulatory labels.
